Napoleon Tall Vector 62" See Through Direct Vent Gas Fireplace with Luminous Logs
The Napoleon Tall Vector 62" See-Through Direct Vent Gas Fireplace with Luminous Logs (TLV62LN2) adds a Luminous Logs burner beside its square tube burner, so flame rises from the logs themselves, above a modulating electric ember bed. It shows the fire to two rooms through a 64-9/16" wide by 26-13/16" tall viewing area on each side, and it runs on natural gas through a 5" x 8" direct vent system.
Dreamwood Living supplies the Tall Vector with Luminous Logs to homeowners, designers and builders who want the look of a wood fire in a modern linear fireplace. A Luminous Log Burner Kit in driftwood, oak or birch is required to complete the fireplace and is sold separately.
Why the Napoleon Tall Vector 62" See-Through with Luminous Logs Stands Out
The Luminous Logs burner runs alongside the square tube burner, and split flow lets you switch the Luminous Logs burner on or off from the remote. The modulating electric ember bed and top accent lighting add glow beneath and above the logs, and NIGHT LIGHT™ dimmer control sets the mood when the fire is off.
The see-through design shows the fire from both sides, so one appliance serves two rooms. The battery back-up control system keeps on/off and flame height control working during a power failure, and the black premium safety barrier is included.
Explore Gas Fireplaces
Key Features
- Up to 44,000 BTU/hr input (natural gas)
- Luminous Logs with modulating electric ember bed for a lifelike appearance
- Luminous Logs burner and square tube burner with flame adjustment; split flow switches the Luminous Logs burner on or off
- Luminous Log Burner Kit required (driftwood, oak or birch), sold separately
- Tall 64-9/16" x 26-13/16" viewing area on each side
- Heat-radiating ceramic glass
- Black premium safety barrier included
- Top accent lighting with NIGHT LIGHT™ dimmer control
- ProFlame II remote and eFIRE controller included (app control via Bluetooth)
- Battery back-up control system
- MIRRO-FLAME™ porcelain reflective radiant panels included
- Firestop / vent shield
- Stainless steel flex connector
- Easy-access air control
- Optional heat management: LHAD, DHC, DHC+ or DHM
- Approved for bedroom and bathroom installations
- President’s Lifetime Limited Warranty
What to Order With It
Required (choose one):
-
Luminous Log Burner Kit for the 62" – Driftwood (DLKTLV62L), Oak (OLKTLV62L) or Birch (BLKTLV62L). Each kit includes the logs, rocks, glowing embers, charcoal, shale, glass and vermiculite.
Required (choose one vent terminal):
Optional:
Specifications
| Model |
TLV62LN2 (natural gas) |
| Type |
Direct Vent |
| Installation |
Built-in |
| Style |
Tall linear with Luminous Logs, see-through |
| Fuel Type |
Natural Gas |
| Ignition |
Electronic, pilot-on-demand |
| Certification |
Vented decorative gas appliance (CSA 2.22 / ANSI Z21.50) |
| Maximum Input, Natural Gas |
44,000 BTU/hr |
| Minimum Input, Natural Gas |
25,000 BTU/hr |
| Viewing Area |
64-9/16" W x 26-13/16" H (each side) |
| Venting |
Top 5" exhaust / 8" air intake; up to 20 ft horizontal or 40 ft vertical |
| Burner |
Luminous Logs burner + square tube burner with flame adjustment |
| Media |
Luminous Log Burner Kit required (sold separately) |
| Controls |
ProFlame II remote and eFIRE controller (included); wall mount control optional |
| Heat Management Kit |
LHAD, DHC, DHC+ or DHM (optional) |
| Warranty |
President’s Lifetime Limited Warranty |
Appliance Dimensions
| Overall Width |
77-5/16" |
| Overall Height |
49-7/16" |
| Overall Depth |
16-3/16" |
Minimum Framing Dimensions
| Framing Width |
77-13/16" |
| Framing Height |
48-3/16" |
| Framing Depth |
16-3/16" |
| Minimum Enclosure / Ceiling Height |
91" (measured from the bottom of the appliance) |
The finishing flange defines the perimeter of the fireplace opening; framing or finishing materials must never encroach inside it. Some venting configurations that require more vertical rise need a larger enclosure. Refer to the installation manual for complete framing, venting and clearance requirements.
Frequently Asked Questions
What is the gas input of the Tall Vector 62 See-Through with Luminous Logs?
The TLV62LN2 has a maximum input of 44,000 BTU/hr and a minimum of 25,000 BTU/hr on natural gas. It is certified as a vented decorative gas appliance.
Are the logs included?
No. Napoleon lists the Luminous Log Burner Kit as a mandatory option, sold separately. Choose driftwood, oak or birch in the 62" size.
What size enclosure does it need?
Frame 77-13/16" wide, 48-3/16" high and 16-3/16" deep, with a minimum enclosure/ceiling height of 91" measured from the bottom of the appliance. Always confirm against the installation manual for your venting configuration.
Does the fireplace still work during a power outage?
Yes. The battery back-up control system keeps on/off and flame height control working during a power failure.
Documents & Downloads
Warranty
Napoleon Warranty
Napoleon products are designed with superior components and materials and assembled by trained craftsmen who take great pride in their work. Once assembled, the complete appliance is thoroughly inspected by a qualified and authorized installer, service agency, or supplier before packing to ensure that you, the customer, receive the quality product that you expect from Napoleon. (Registered under the world recognized ISO 9001 : 2015).
Gas Fireplaces – President’s Lifetime Limited Warranty
The following are warranted against defects for as long as you own the appliance: combustion chamber, heat exchanger, stainless / steel burner, PHAZER® logs and embers, rocks, ceramic glass (thermal breakage only), gold plated parts against tarnishing, porcelainized enameled components and aluminum extrusion trims.* During the first 10 years Napoleon will repair or replace defective parts covered by the lifetime warranty free of charge. From 10 years to life, Napoleon will provide replacement parts at 50% of the current retail price.
Electrical (110V and millivolt) components and wearable parts are covered during the first year: blowers, gas valves, thermal switches, switches, wiring, remote controls, ignitors, gaskets and pilot assemblies.* Labour related to warranty repair is covered during the first year (not applicable to gas log sets) and must be done through an authorized Napoleon dealer.
*Construction of models varies. Warranty applies only to components included with your specific appliance.
*PLEASE REFER TO PRODUCT MANUAL FOR EXACT INSTALLATION INSTRUCTIONS.
