The ultimate in Zero Clearance Direct Vent Fireplaces for new home construction or renovation, and your best choice for installation anywhere throughout your home. Warm up your favorite room with the beauty of a Linear Fireplace.
*Venting Requirements: This unit requires venting pipe with an inner diameter of 5 Inches. Please see the Venting Components section on this page if available for venting pipe that must be used with this unit.
Model | ZCVRB60N/NE | ZCVRB60LP/LPE |
Fuel | Natural | Propane |
Flue | Top | Top |
Gas Control | Millivolt / IPI | Millivolt / IPI |
Input Max. | 35,000 BTU | 35,000 BTU |
Input Min. | 23,000 BTU | 28,000 BTU |
FE (p.4.1-02)% | 55.27% / 56.66% | 55.27% / 56.66% |
Flue Size | 5”/8” |
5”/8” |
Glass Size | 60" W x 17 7/8" H |
60" W x 17 7/8" H |
Glass Type | Tempered | Tempered |
Size (WxHxD) | 66 3/16” x 39 9/16” x 19 3/8” |
66 3/16” x 39 9/16” x 19 3/8” |
Viewing Area |
61 1⁄8” x 19 15/16” |
61 1⁄8” x 19 15/16” |
Venting | 5” Flex or 8” Hard Pipe |
5” Flex or 8” Hard Pipe |
Electronic Ignition |
NO / YES |
NO / YES |
Certification |
Heater | Heater |
Bedroom Approved | Yes | Yes |
Conversion Kit
Conversion Kit to Propane Millivolt (60ZCVRB-CKLP)
Conversion Kit to Natural Gas Millivolt (60ZCVRB-CKNG)
Conversion Kit to Propane IPI (60ZCVRB-CKLPI)
Conversion Kit to Natural Gas IPI (60ZCVRB-CKNGI)
|
Enclosure Grill
Enclosure Ventilation Grill Front (VL60EG)
|
Surrounds Trim Kit
Stainless Steel Surround Trim Kit (ZCVRB60S1SS)
|
|
Black Surround Trim Kit (ZCVRB60S1BL)
|
Liner Kit
3 Piece Porcelain Reflective Liner Kit (ZCVRB60PL)
|
Assorted Cannonball
Assorted Cannonball (RBCB1)
|
Fan Kit
Speed Temperature Sensing Fan Kit (Z46FK)
|
Accent Lighting
Universal Light Kit (ULK64)
|
Tile Lip Kit
Tile Lip Kit (V60PTLK)
|
Thermostat
Wall Mount Thermostat- For Millivolt Units (Z2MT)
Programmable Digital Wall Mount Thermostat- For Millivolt Units (Z80PT)
|
Remote Control
On/Off Remote Control for Millivolt/IPI Units (GFRC)
|
|
Thermostat Remote Control Millivolt/IPI Units (GTRC, EGTRC)
|
|
Thermostat On/Off modulating for Natural Gas/Propane Millivolt/IPI Units
|
|
Thermostat On/Off modulating and fan control for Natural Gas/Propane Millivolt/IPI Units (GTFRCN, GTFRCP, EGTFRCN, EGTFRCP)
|
venting products
Horizontal Vent Starter Kit for 5x8-Inch Venting - Z58HSK5 | |
When your chimney twists and turns, the Horizontal Flex Vent Chimney Pipe Starter Kit can help the smoke navigate its way out of the house. Includes 5 ft. of flex pipe, termination, and wall thimble | |
45-Degree DirectVent Pro Elbow - 58DVA-E45 | |
Use to offset obstructions as needed. Fully unitized, twist-lock construction. Elbows swivel, allowing the lock to remain fully engaged while aligning to the desired direction. The angle will remain fixed at 45°. Finish: Galvanized & Black. | |
90-Degree DirectVent Pro Elbow - 58DVA-E90 |
|
Use to offset obstructions as needed. Fully unitized, twist-lock construction. Elbows swivel, allowing the lock to remain fully engaged while aligning to the desired direction. The angle will remain fixed at 90°. Finish: Galvanized & Black. | |
5"x8" DirectVent Pro Pipe Length | |
Features a fully unitized twist-lock construction in both 4” x 6 5⁄8” and 5” x 8” vent sizes. Use of sealant is optional unless specified by the appliance manufacturer. Finish: Galvanized & Black. |
|
5"x8" DirectVent Pro Pipe Extension | |
Use to add length to a straight length of DirectVent Pro. 8 ½” pipe adds 3”- 7” of length, 16” pipe adds 3”- 14 ½” of length when used with rigid sections of pipe. Direct vent lengths feature a fully unitized, twist-lock construction. Available in black or galvalume exterior. |
|
5"x8" DirectVent Pro Adjustable Pipe | |
Use of sealant is optional unless specified by the appliance manufacturer. Available in black or galvalume exterior. |
|
DirectVent Pro Wall Strap - 58DVA-WS | |
Use to support vent pipe. Provides 1” clearance. Recommend installing Wall Straps at 4-foot intervals on vertical runs. | |
DirectVent Pro Ceiling Firestop - 58DVA-FS | |
Required for multi-story vertical installations on the second floor and any subsequent floors. | |
DirectVent Pro Attic Insulation Shield - 58DVA-IS | |
Required for installations that pass through an attic to prevent insulation and debris from accumulating near the vent. Provides 1” clearance to combustibles. |
|
DirectVent Pro Adjustable Roof Flashing - 58DVA-F6 | |
Use to weatherproof the penetration of vent pipe through the roof. Select roof flashing based on pitch of the roof. For pitches of 0/12 - 6/12. Storm Collar required. Made of galvalume. | |
DirectVent Pro Steep Roof Flashing - 58DVA-F12 | |
Use to weatherproof the penetration of vent pipe through the roof. Storm Collar required. Made of galvalume. | |
DirectVent Pro Dead Soft Aluminum Flashings - 58DVA-F6DS | |
Available in sizes 4”x 6 5⁄8” and 5”x 8”, in 0/12-6/12 (shown) and 7/12-12/12 styles. Made of malleable dead soft aluminum. Use with metal or tile roofs. | |
DirectVent Pro Storm Collar - 58DVA-SC | |
Use to maintain a weather tight resistant seal between the pipe and the flashing. | |
DirectVent Pro High-Wind Termination Cap - 58DVA-VCH | |
Available in aluminum. Use for vertical terminations only. For vertical terminations only. Provides improved performance in high wind conditions. | |
DirectVent Pro Low-Profile Termination Cap - 58DVA-VC | |
Available in aluminum and stainless steel (S). Use for vertical terminations only. Check the appliance manufacturer’s instructions to determine which caps are approved for use with their appliance. | |
DirectVent Pro Wall Thimble - 58DVA-WT |
|
Use with Square Horizontal Cap only. Provides a complete wall-pass-through and firestop. Refer to the appliance manufacturer’s installation instructions for requirements. |
|
DirectVent Pro Square Horizontal Termination Cap - 58DVA-HC | |
Use for standard and high-wind through-the-wall termination. Check installation instructions for restrictions on horizontal cap terminations. Available in aluminum, stainless steel (S), and copper (C). | |
5'/8'/20' Expanded Flex Kit Comes with Springs, Screws and Mill Pac | |
This Flex Kit is designed to be used as a part of the Horizontal Vent Starter Kit for 5/8" Chimney Collection. The kit measures 5" by 8" in diameter and measures 5', 8' and 20' long when stretched. |
|
5"/8" Flex Connector - ZDV5FC, ZDV8FC | |
This chimney vent is equipped with a flex connector that measures five / eight inches in diameter. |
|
5"/8" Flex Clamp - ZDV5FCL, ZDV8FCL | |
This clamp is 5 / 8 inches in diameter. Although the chimney or chimney vent isn't included during this purchase, these things are available for individual sale. Strong enough to withstand pressure |
|
4" Standoff Spring Spacer - ZDV4SS | |
Spring standoff spacer is simply the part needed for your chimney vent. This spring spacer measures 4 inches in diameter and has the potential of withstanding years of use. This spacer also will keep its polishing color. | |
5/8" Horizontal Round Vent Termination - Z58HT | |
This Round Horizontal Chimney Pipe Vent Termination provides a circle termination for your chimney. |
|
Horizontal Wall Thimble Shield for Low Enclosures - Z58WTS |
|
The horizontal wall thimble is a shield for low enclosures and helps traps any unwanted particles in the air. this is often just one type of enclosures that Kingsman provides. |
|
Universal Safety Cage for Horizontal Termination - FDVHSCU | |
Universal Safety Cage. Designed for Horizontal Termination. Use with Horizontal Vent Starter Kit. | |
8" Roof Flashing with Storm Collar - Z58AAF, Z58AF2, Z58AF3 |
|
The roof flashing with storm collar purchase is one of delicate workmanship combined with lasting durability. This storm collar measures 8" in inner diameter. This product has the capability of sealing the vent lengths that protrude from a sloped roof. |
|
8" Storm Collar for Venting - ZDV8SC |
|
Storm Collars are useful for wetter climates as they divert water from vertical pipes to the flashing around. This Storm Collar will effortlessly snap around the vent pipe and fasten into place, providing you the peace of mind. This Kingsman Storm Collar matches the Kingsman 5"/8" vent systems. |
|
5/8" Vertical Chimney Vent Termination - Z58VT | |
It's designed for 5/8" chimney pipes. In fact, it's just one of the various parts that make up the Horizontal Vent Starter Kit Collection for 5/8" Chimneys. |
|
24" Attic Insulation Shield - Z58AIS24 | |
This shield will protect your attic and roof from the heat that escapes through the chimney. The shield offers 24" of insulation designed to surround your chimney. |
|
Vertical Chimney Vent Offset Support - ZDVVOS | |
It'll support your chimney through inclement weather, including heavy rain, snow accumulation, and wind, also as natural wear from gravity over time. The support has been tested for durability and function. | |
Firestop Spacer for 5x8" Venting - Z58FS | |
This Chimney Vent Firestop Spacer provides space between the heat of the smoke going up the chimney. This piece is designed to be used as a part of the Horizontal Vent Starter Kit for the 5/8" Chimney Collection. |
|
Roof Support for Venting - Z58RS | |
Designed to be used with 5/8" chimney. Part of the Horizontal Vent Starter Kit for 5/8" chimneys | |
Hard Chimney Pipe Adapter - Z58DFA | |
This Hard Chimney Pipe Adapter is just one item in the Horizontal Power Vent Starter Kit for 5/8" Chimney Collection. |
|
DirectVent Pro Vinyl Sliding Standoff - 58DVA-VSS | |
Use as a heat shield on structures with vinyl siding, or other temperature-sensitive materials, to help prevent warping and or melting of the material. | |
DirectVent Pro Horizontal Windguard - 46DVA-WG |
|
Fits both 4” x 6 5⁄8” and 5” x 8” terminations. Use with through-the-wall termination cap where high winds are present. Use as a safety heat shield to prevent children or others from coming into contact with the vent termination cap. |
